Description

Camden CM-30U LED Push Exit Square Switch with English & Spanish Labels – 12V-28V

CM-30 Series UL compliant LED illuminated request to exit (REX) switches conform to NFPA code requirements and are ADA compliant. They are designed to control electric locks, electromagnetic locks, electric strikes and low energy door operators. They may also be used for shunting, bypassing alarms, request to exit, timed functions and many other applications. Where electronic time delay is required (i.e. door held open), Camden offers model CM-30EE with double break circuitry.

Features:

• High visibility 2 square button
• Single gang stainless steel faceplate
• C and U models offer the largest selection of insert labels (see info below for labels included)
• E model offers economical single label Push to Exit version
• LED bulb provides super-bright operation and longevity (10 year estimate)
• 3 year warranty with 2 for 1 replacement

• Specifications:

  Voltage:		12 24 VDC
  Contact Type:		SPDT Form C
  Contact Rating:		10 A @ 30 VDC
  Switch Type:		Momentary
  Current Draw:		LED Bulb: 14 mA
  Dimensions:		4-1 2 x 2-3 4 x 1-7 8 ” (114.mm x 70mm x 48mm)
  Std. Finish:		US32 C32D

  Spacification Sheets:

  • CM-30_Spec Sheet_R5

  • Manuals:

    • CM-30C&U_Manual
    • CM-30_Wiring Diagram

    • Reference Guides:

      • Push Button Switch_Cross Reference

      • Videos:

        • Product Comparison
